ID: 17614
Omschrijving
Te koop als occasion,
Set van 2 stuks Meyer Sound 700HP in zeer nette staat, geen touring subs enkel gebruikt voor jazz en gospel muziek. 5250,- euro ex btw voor beide samen, incl 3 maanden garantie. (6352,50 incl btw)
Gepowerde dubbel 18 inch sub (2x 1125W ingebouwde versterker)
Meyer Sound 700HP
The 700-HP's power and bandwidth handle high continuous operating levels and extreme transient information with minimal distortion in its operating frequency range.
Meyer Sounds rigorous design approach has been applied to extract the greatest efficiency from every part of the system, resulting in the 700-HPs effortless reproduction of low frequency transient information. As a self-powered system, the transducers, amplification and control electronics of the 700-HP are created as a symbiotic system that optimizes performance and maximizes its tremendous power.
The operating frequency range of 28 Hz to 150 Hz complements other Meyer Sound loudspeakers and line and curvilinear arrays in sound reinforcement applications requiring maximum headroom at the low end of the frequency spectrum.
The 700-HP's efficiently tuned cabinet houses two Meyer Sound-designed and -manufactured back-vented, long-excursion, 18-inch cone drivers. Each driver features a 4-inch voice coil and is rated to handle 1200 AES watts. The drivers have also been engineered for extreme efficiency, using high-gauss neodymium magnets for the most powerful magnetic field strength. High magnetic field strength increases the drivers sensitivity, which yields greater output, while keeping heat dissipation requirements within operational tolerances.
An integral two-channel class AB/H amplifier with complementary MOSFET output stages supplies total peak power of 2250 watts (1125 watts per channel). With twice the amplifier power of the 650-P subwoofer, the 700-HP produces an average of 3 dB more overall SPL, with enormous headroom to accommodate the most extreme demands with ease. Recent tests conducted by Meyer Sound show the 700-HP producing significantly higher output than other "high-power" subwoofers.
The amplifier, control electronics and power supply are integrated into a single, field-replaceable module mounted in the rear of the cabinet. The cabinet is constructed of multi-ply hardwood and coated with a textured black finish. Integral metal grilles lined with acoustical black mesh protect the cone drivers. Designed mainly for stage or ground placement, the stackable 700-HP includes plastic skids on the bottom of the unit, preventing damage to the enclosure or the unit below. The skids align with slots on the cabinets upper surfaces ensuring secure, aligned stacking. For maximum convenience in touring situations, the 700-HP can even travel in stacks on the MCF-700 caster frame.
The 700-HP is truck-smart, with exterior cabinet dimensions suitable for both European and US truck widths. An optional QuickFly rigging kit is available, installed at the factory or as a field upgrade. Up to 10 cabinets can be suspended from the optional MTG-700 top grid in a straight hang at a 7:1 safety factor.
Specification
28 Hz - 150 Hz
30 Hz - 125 Hz ±4 dB
45 Hz - 145 Hz ±30°
139 dB piek
>110 dB
360° (single unit); varies with number of units and configuration
Two 18" cone drivers
Nominal impedance: 4 ohm
Voice coil size: 4"
Power-handling capability: 1200 W (AES)4
Differential, electronically balanced
±15 V DC, clamped to earth for voltage transient protection
Female XLR input with male XLR loop output or VEAM all-in-one
(integrates AC, audio and network)?
10 k? differential between pins 2 and 3?
Pin 1: Chassis/earth through 220 k?, 1000 pF, 15 V clamp network to
provide virtual ground lift at audio?frequencies
Pin 2: Signal +
Pin 3: Signal -
Case: Earth ground and chassis
None on input, DC blocked through signal processing
>50 dB, typically 80 dB (50 Hz500 Hz)
Common mode: 425 kHz
Differential mode: 142 kHz
Integral to signal processing (<80 kHz)
0 dBV (1 V rms, 1.4 V pk) continuous is typically the onset of limiting for
noise and music
Audio source must be capable of producing a minimum of +20 dBV (10
V rms, 14 V pk) into 600 ? in?order to produce maximum peak SPL over
the operating bandwidth of the loudspeaker
Two-channel complementary power MOSFET output stages (class AB/H)
2250 W (1125 W/channel)5
<.02%?
4 ? each channel
Forced air cooling, two fans (one ultrahigh-speed reserve fan)
U betaald geen BTW met uw Belgisch / buitenlands BTW nummer
Zie ook onze andere advertentie's, inruil is mogelijk.
Al onze occasions zijn gecontroleerd door onze TD!
Neem contact op voor onze lease opties! (enkel voor zakelijke klanten)
Wij verzenden door heel Eurpoa / we ship worldwide
Met vriendelijke groet,
Team Soundsale
Gasthuisgraaf 13
6136KS Sittard (NL)
0031(0)46 7009711
Zie ook onze website voor meer occasions!
